WRFA
Adaptateur à bride Wide-Range (pièce EU)
Adaptateur à bride pour le raccordement de tuyaux de différents matériaux (acier, fonte, fonte ductile, amiante-ciment, PVC, PE-HD/PEX).
- Boîtier et bague de suivi en acier
- Protection anticorrosion Rilsan (min. 250 µm selon GSK)
- Vis et écrous galvanisés/revêtus de sheraplex ou en acier inoxydable
- Matériau du joint EPDM
- Tolérance de diamètre max. 17 mm
- Possibilité de couder les tubes de 3 degrés max.
- Dimensions des raccords à bride selon DIN EN1092, PN 10 et PN 16
- Plage de température : -20°C - +30°C
Remarque:
En cas d'application sur des tubes PE-HD/PEX, notre douille de soutien interne SHVA est nécessaire. Comme alternative, nous recommandons le produit FRIAGRIP à adhérence longitudinale.
Adaptateur à bride Wide-Range (pièce EU)
| Référence | product.detail.attribute.dSmall | DN | product.detail.attribute.flanschDN | product.detail.attribute.flanschPN | product.detail.attribute.L_String | product.detail.attribute.weight | product.detail.attribute.packUnit | product.detail.attribute.palletUnit |
|---|---|---|---|---|---|---|---|---|
| GB-14R9-351-30 | 351,0-368,0 | 500 | 300 | 10 | 400 | 57,000 | 1 | 4 |
| GB-16R9-351-30 | 351,0-368,0 | 500 | 300 | 16 | 400 | 57,000 | 1 | 4 |
| GB-14R9-374-35 | 374,5-391,5 | 500 | 350 | 10 | 400 | 38,100 | 1 | 2 |
| GB-16R9-374-35 | 374,5-391,5 | 500 | 350 | 16 | 400 | 38,100 | 1 | 2 |
| GB-14R9-394-35 | 394,3-411,3 | 500 | 350 | 10 | 400 | 45,300 | 1 | 1 |
| GB-16R9-394-35 | 394,3-411,3 | 500 | 350 | 16 | 400 | 39,800 | 1 | 1 |
| GB-14R9-404-40 | 404,8-421,8 | 500 | 400 | 10 | 400 | 37,900 | 1 | 1 |
| GB-16R9-404-40 | 404,8-421,8 | 500 | 400 | 16 | 400 | 39,600 | 1 | 1 |
| GB-14R9-425-40 | 425,0-442,0 | 500 | 400 | 10 | 400 | 35,500 | 1 | 1 |
| GB-16R9-425-40 | 425,0-442,0 | 500 | 400 | 16 | 400 | 35,500 | 1 | 1 |
| GB-14R9-447-40 | 447,2-464,2 | 500 | 400 | 10 | 400 | 45,900 | 1 | 1 |
| GB-16R9-447-40 | 447,2-464,2 | 500 | 400 | 16 | 400 | 45,900 | 1 | 1 |
| GB-14R9-455-40 | 455,0-472,0 | 500 | 400 | 10 | 400 | 50,000 | 1 | 1 |
| GB-16R9-455-40 | 455,0-472,0 | 500 | 400 | 16 | 400 | 45,600 | 1 | 1 |
| GB-14R9-501-45 | 501,9-518,9 | 500 | 450 | 10 | 400 | 53,700 | 1 | 1 |
| GB-16R9-501-45 | 501,9-518,9 | 500 | 450 | 16 | 400 | 53,700 | 1 | 1 |
| GB-14R9-501-50 | 501,9-518,9 | 500 | 500 | 10 | 400 | 53,700 | 1 | 1 |
| GB-16R9-501-50 | 501,9-518,9 | 500 | 500 | 16 | 400 | 53,700 | 1 | 1 |
| GB-14R9-510-50 | 510,0-527,0 | 500 | 500 | 10 | 400 | 48,000 | 1 | 1 |
| GB-16R9-510-50 | 510,0-527,0 | 500 | 500 | 16 | 400 | 53,000 | 1 | 1 |
| GB-14R9-527-50 | 527,0-544,0 | 500 | 500 | 10 | 400 | 42,900 | 1 | 1 |
| GB-16R9-527-50 | 527,0-544,0 | 500 | 500 | 16 | 400 | 50,500 | 1 | 1 |
| GB-14R9-540-50 | 540,1-557,1 | 500 | 500 | 10 | 400 | 50,500 | 1 | 1 |
| GB-16R9-540-50 | 540,1-557,1 | 500 | 500 | 16 | 400 | 50,500 | 1 | 1 |
| GB-14R9-555-50 | 555,3-572,3 | 500 | 500 | 10 | 400 | 62,000 | 1 | 1 |
| GB-16R9-555-50 | 555,3-572,3 | 500 | 500 | 16 | 400 | 64,000 | 1 | 1 |
| GB-14R9-566-50 | 566,5-583,5 | 500 | 500 | 10 | 400 | 62,200 | 1 | 1 |
| GB-16R9-566-50 | 566,5-583,5 | 500 | 500 | 16 | 400 | 62,200 | 1 | 1 |
| GB-14R9-582-50 | 582,2-599,2 | 500 | 500 | 10 | 400 | 54,200 | 1 | 1 |
| GB-16R9-582-50 | 582,2-599,2 | 500 | 500 | 16 | 400 | 62,500 | 1 | 1 |
| GB-14R9-601-60 | 601,0-618,0 | 500 | 600 | 10 | 400 | 63,000 | 1 | 1 |
| GB-16R9-601-60 | 601,0-618,0 | 500 | 600 | 16 | 400 | 65,500 | 1 | 1 |
| GB-14R9-630-60 | 630,5-647,5 | 500 | 600 | 10 | 400 | 63,400 | 1 | 1 |
| GB-16R9-630-60 | 630,5-647,5 | 500 | 600 | 16 | 400 | 66,100 | 1 | 1 |
| GB-14R9-645-60 | 645,2-662,2 | 500 | 600 | 10 | 400 | 63,100 | 1 | 1 |
| GB-16R9-645-60 | 645,2-662,2 | 500 | 600 | 16 | 400 | 63,700 | 1 | 1 |
| GB-14R9-675-60 | 675,0-692,0 | 500 | 600 | 10 | 400 | 64,400 | 1 | 1 |
| GB-16R9-675-60 | 675,0-692,0 | 500 | 600 | 16 | 400 | 78,000 | 1 | 1 |
Adaptateur à bride Wide-Range (pièce EU)
| Référence | product.detail.attribute.dSmall | DN | product.detail.attribute.flanschDN | product.detail.attribute.flanschPN | product.detail.attribute.L_String | product.detail.attribute.weight | product.detail.attribute.packUnit | product.detail.attribute.palletUnit |
|---|---|---|---|---|---|---|---|---|
| GB-14R9X351-30 | 351,0-368,0 | 500 | 300 | 10 | 400 | 32,800 | 1 | 4 |
| GB-16R9X351-30 | 351,0-368,0 | 500 | 300 | 16 | 400 | 42,000 | 1 | 4 |
| GB-14R9X374-35 | 374,5-391,5 | 500 | 350 | 10 | 400 | 38,100 | 1 | 2 |
| GB-16R9X374-35 | 374,5-391,5 | 500 | 350 | 16 | 400 | 38,100 | 1 | 2 |
| GB-14R9X394-35 | 394,3-411,3 | 500 | 350 | 10 | 400 | 37,900 | 1 | 1 |
| GB-16R9X394-35 | 394,3-411,3 | 500 | 350 | 16 | 400 | 37,900 | 1 | 1 |
| GB-14R9X404-40 | 404,8-421,8 | 500 | 400 | 10 | 400 | 36,000 | 1 | 1 |
| GB-16R9X404-40 | 404,8-421,8 | 500 | 400 | 16 | 400 | 39,600 | 1 | 1 |
| GB-14R9X425-40 | 425,0-442,0 | 500 | 400 | 10 | 400 | 35,500 | 1 | 1 |
| GB-16R9X425-40 | 425,0-442,0 | 500 | 400 | 16 | 400 | 33,700 | 1 | 1 |
| GB-14R9X447-40 | 447,2-464,2 | 500 | 400 | 10 | 400 | 48,000 | 1 | 1 |
| GB-16R9X447-40 | 447,2-464,2 | 500 | 400 | 16 | 400 | 48,000 | 1 | 1 |
| GB-14R9X455-40 | 455,0-472,0 | 500 | 400 | 10 | 400 | 41,100 | 1 | 1 |
| GB-16R9X455-40 | 455,0-472,0 | 500 | 400 | 16 | 400 | 41,100 | 1 | 1 |
| GB-14R9X501-45 | 501,9-518,9 | 500 | 450 | 10 | 400 | 53,700 | 1 | 1 |
| GB-16R9X501-45 | 501,9-518,9 | 500 | 450 | 16 | 400 | 53,700 | 1 | 1 |
| GB-14R9X501-50 | 501,9-518,9 | 500 | 500 | 10 | 400 | 53,700 | 1 | 1 |
| GB-16R9X501-50 | 501,9-518,9 | 500 | 500 | 16 | 400 | 53,700 | 1 | 1 |
| GB-14R9X510-50 | 510,0-527,0 | 500 | 500 | 10 | 400 | 50,000 | 1 | 1 |
| GB-16R9X510-50 | 510,0-527,0 | 500 | 500 | 16 | 400 | 53,000 | 1 | 1 |
| GB-14R9X527-50 | 527,0-544,0 | 500 | 500 | 10 | 400 | 50,500 | 1 | 1 |
| GB-16R9X527-50 | 527,0-544,0 | 500 | 500 | 16 | 400 | 50,500 | 1 | 1 |
| GB-14R9X540-50 | 540,1-557,1 | 500 | 500 | 10 | 400 | 50,500 | 1 | 1 |
| GB-16R9X540-50 | 540,1-557,1 | 500 | 500 | 16 | 400 | 50,500 | 1 | 1 |
| GB-14R9X555-50 | 555,3-572,3 | 500 | 500 | 10 | 400 | 62,000 | 1 | 1 |
| GB-16R9X555-50 | 555,3-572,3 | 500 | 500 | 16 | 400 | 64,000 | 1 | 1 |
| GB-14R9X566-50 | 566,5-583,5 | 500 | 500 | 10 | 400 | 62,200 | 1 | 1 |
| GB-16R9X566-50 | 566,5-583,5 | 500 | 500 | 16 | 400 | 62,200 | 1 | 1 |
| GB-14R9X582-50 | 582,2-599,2 | 500 | 500 | 10 | 400 | 54,200 | 1 | 1 |
| GB-16R9X582-50 | 582,2-599,2 | 500 | 500 | 16 | 400 | 60,000 | 1 | 1 |
| GB-14R9X601-60 | 601,0-618,0 | 500 | 600 | 10 | 400 | 63,000 | 1 | 1 |
| GB-16R9X601-60 | 601,0-618,0 | 500 | 600 | 16 | 400 | 65,500 | 1 | 1 |
| GB-14R9X630-60 | 630,5-647,5 | 500 | 600 | 10 | 400 | 63,400 | 1 | 1 |
| GB-16R9X630-60 | 630,5-647,5 | 500 | 600 | 16 | 400 | 66,100 | 1 | 1 |
| GB-14R9X645-60 | 645,2-662,2 | 500 | 600 | 10 | 400 | 63,100 | 1 | 1 |
| GB-16R9X645-60 | 645,2-662,2 | 500 | 600 | 16 | 400 | 63,700 | 1 | 1 |
| GB-14R9X675-60 | 675,0-692,0 | 500 | 600 | 10 | 400 | 64,400 | 1 | 1 |
| GB-16R9X675-60 | 675,0-692,0 | 500 | 600 | 16 | 400 | 78,000 | 1 | 1 |
| GB-14R9X689-60 | 689,0-706,0 | 500 | 600 | 10 | 400 | 90,300 | 1 | 1 |
| GB-16R9X689-60 | 689,0-706,0 | 500 | 600 | 16 | 400 | 90,300 | 1 | 1 |
| GB-14R9X710-70 | 710,0-727,0 | 500 | 700 | 10 | 400 | 70,000 | 1 | 1 |
| GB-16R9X710-70 | 710,0-727,0 | 500 | 700 | 16 | 400 | 66,500 | 1 | 1 |
| GB-14R9X733-70 | 733,0-750,0 | 500 | 700 | 10 | 400 | 74,000 | 1 | 1 |
| GB-16R9X733-70 | 733,0-750,0 | 500 | 700 | 16 | 400 | 90,300 | 1 | 1 |
